Lever Type Load Binder

Quickly and easily tighten down chains to secure heavy loads with this durable steel load binder.
Powder coat finish resists corrosion.
Load binder lets you secure loads and tighten chains quickly and easily.
Perfect for agricultural and industrial tie-down applications.
Lever mechanism has fewer moving parts than a ratchet binder and requires less maintenance.
Forged steel construction is strong and durable.
Powder coat finish provides excellent resistance to corrosion.

Model Number

LLB-10
LLB-12
Data sheets
Model LLB-10 LLB-12
Code 108356 108357
Min-Max chain size 5/16"-3/8" 3/8"-1/2"
Working Load Limit 5400LBS 9200LBS
Proof Load 10800LBS 18400LBS
Minimum Uitmate Strength 19000LBS 33000LBS
Handle Lengh 15.43" 17.24"
Size A 25.2mm 28.5mm
Size B 23.2mm 26.38mm
Size C 18.49mm 22.05mm
Size D 15.55mm 17.64mm
Size E 11.22mm 12.99mm
Size F 11.22mm 12.2mm
Size G 0.51mm 0.59mm
Single Weight 3.5kgs 5.5kgs
Q’ty/Ctn 6pcs 5pcs
N.W./G.W. 21/22kgs 27.5/28.5kgs
